OR80SLM (Silver Lining Membrane)

Coating Description

100% solids, 2 components, spray applied, pure polyurea elastomer. OR80SLM is a tough, rapid set; high build coating that is, VOC compliant and moisture tolerant. This coating performs with superior reflective qualities for cool roofing systems. Superior UV resistance and Miami Dade

Approved.

Primary Application

• Protective coating for metal and built-up roofs
• Protective coating for urethane and expanded polystyrene insulation
• Protective coating for worn out EPDM roofing
• Secondary containment when applied over concrete, wood or geotextiles
• Protective coating for decorative products
• Wearing and waterproofing membrane for pedestrian decks
• Water proofing of buried, protected or unprotected roofs, walks and concrete walls, with or without spray applied foam insulation.
• Vertical or horizontal application
• Approved for external containment liner or food grade dry bulk goods

Waterproofing Color

Aluminum, dark gray, black, brown, green, custom colors are also available

Chemical Resistance

Good hydrolytic stability to 300˚ F. Good resistance to inorganic bases, acids and hydrocarbon solvents. Fair resistance to oxygenated and chlorinated solvents. For higher chemical resistance use OR70SS

Waterproofing Packaging

A 110-gallon kit consists of two (2) 55 gallon drums

Waterproofing storage life

12 months in unopened containers when stored in a dry location

at 50-90º F (10-32º C)

Waterproofing Product Advantages

Features

• Seamless
• Monolithic waterproofing
• Rapid set
• Back in service sooner
• High moisture tolerance
• Long open application window
• Hi temp range
• Wide product applications
• Easy high film builds
• Reduced labor cost
• 100% solids
• No VOC
• Tough film
• Abrasion resistant
• Long coating life
• Self extinguishing

Application Data

Substrate must be sound, clean and free of dirt, debris and other contaminates. Oak Ridge Foam & Coating Systems, Inc. primers are used on most substrates. No primer is needed for newly applied or cleaned foam OR811 or OR611 primer is recommended for bare metal, old foam, concrete, build up roofs, wood and EPDM. Don not apply below 35° F(1.7°C)

Coverage- 3,500 feet per set

Thoroughly mix Part B of OR80SLM prior to use and continue to mix. Care should be exercised to prevent cross contamination of the A & B.

Application Equipment

High pressure (2500PSI) plural component proportioning equipment with plural component spray gun. Minimum barrel temperature, 70º F and rising. Minimum machine temperature 160º F, minimum machine pressure, 2200 psi. Spray tip requirement .01 or .02 size.

Density

Part A 8.7 lbs/gallon

Part B 9.2 lbs/gallon
